The Ubiquiti UniFi U6+ is an access point designed to bring the benefits of WiFi 6 technology to a broader audience by offering an optimal balance of performance, features, and cost. Utilizing 2×2 DL/UL MU-MIMO technology on both 2.4 GHz and 5 GHz bands, it leverages 160 MHz channel width to deliver a robust maximum data rate of 2.4 Gbps on the 5 GHz band, providing a significant performance uplift over previous-generation AC Wave 2 APs.
Despite its accessible price point, the U6+ does not compromise on the sophisticated feature set expected from the UniFi ecosystem. It includes advanced functionalities such as wireless meshing, band steering, fast roaming (802.11k/v/r), and a full suite of guest management tools, including a customizable captive portal with voucher and payment authentication. Its hardware is designed for efficiency, consuming a maximum of 9W of power and powered via standard PoE, making it easy to deploy in new or existing networks.
Managed through the UniFi Network application (version 7.3.76+), the U6+ is an excellent solution for small to medium-sized businesses, educational settings, and residential applications that seek to upgrade their wireless infrastructure to WiFi 6 without a substantial investment, while still benefiting from enterprise-grade management and security features.
Overview
| Specification | Details |
|---|---|
| WiFi Standard | WiFi 6 (802.11ax) |
| MIMO (5 GHz) | 2×2 (DL/UL MU-MIMO) |
| MIMO (2.4 GHz) | 2×2 (DL/UL MU-MIMO) |
Performance
| Specification | Details |
|---|---|
| Max. Data Rate (5 GHz) | 2.4 Gbps (BW160) |
| Max. Data Rate (2.4 GHz) | 573.5 Mbps (BW40) |
| Antenna Gain (5 GHz) | 5.4 dBi |
| Antenna Gain (2.4 GHz) | 3 dBi |
| Max. TX Power (5 GHz) | 23 dBm |
| Max. TX Power (2.4 GHz) | 23 dBm |
| Max. BSSIDs | 8 per Radio |
| Supported Data Rates | 802.11ax (WiFi 6): 7.3 Mbps to 2.4 Gbps 802.11ac (WiFi 5): 6.5 Mbps to 1.7 Gbps 802.11n: 6.5 Mbps to 300 Mbps |
Features
| Feature | Supported |
|---|---|
| Wireless Meshing | ✓ |
| Band Steering | ✓ |
| 802.11v BSS Transition Management | ✓ |
| 802.11r Fast Roaming | ✓ |
| 802.11k Radio Resource Management (RRM) | ✓ |
| Advanced Radio Management | ✓ |
| Passpoint (Hotspot 2.0) | ✓ |
| Captive Hotspot Portal | ✓ |
| Custom Branding Landing Page | ✓ |
| Voucher Authentication | ✓ |
| Payment-Based Authentication | ✓ |
| External Portal Server Support | ✓ |
| Password Authentication | ✓ |
| Guest Network Isolation | ✓ |
| Private Pre-Shared Key (PPSK) | ✓ |
| WiFi Speed Limiting | ✓ |
| Client Device Isolation | ✓ |
| WiFi Schedules | ✓ |
| RADIUS over TLS (RadSec) | ✓ |
| Dynamic RADIUS-assigned VLAN | ✓ |
Hardware
| Specification | Details |
|---|---|
| Max. Power Consumption | 9W |
| Supported Voltage Range | 44—57V DC |
| Networking Interface | (1) GbE RJ45 Port |
| Weight (Device Only) | 338 g (11.9 oz) |
| Weight (With Mount) | 413 g (14.6 oz) |
| Management | Ethernet |
| Enclosure Material | Polycarbonate, Aluminum |
| Mount Material | ABS, SGCC Steel |
| LEDs | System: White/Blue |
| NDAA Compliant | ✓ |
| Certifications | CE, FCC, IC, Anatel, SRRC |
| Operating Frequency | US/CA: 2.4 GHz: 2400-2472 MHz; 5 GHz: 5150-5250, 5250-5350, 5470-5725, 5725-5850 MHz Worldwide: 2.4 GHz: 2400-2483.5 MHz; 5 GHz: 5150-5725 MHz |
| Operating Temperature | -30 to 60° C (-22 to 140° F) |
| Operating Humidity | 5 to 95% non-condensing |
Software
| Specification | Details |
|---|---|
| Application Requirements | UniFi Network Version 7.3.76 and later |
