The Ubiquiti UniFi U7 Lite is an accessible entry point into the WiFi 7 ecosystem, designed to provide next-generation wireless performance for cost-sensitive deployments without compromising on essential enterprise features. This compact access point leverages the 802.11be standard with 4 spatial streams and 2×2 DL/UL MU-MIMO technology across both 2.4 GHz and 5 GHz bands to deliver impressive wireless speeds up to 4.3 Gbps on the 5 GHz band using 240 MHz channel width.
Despite its budget-friendly positioning, the U7 Lite includes a 2.5 GbE uplink port to ensure no network bottleneck and is powered via standard PoE for easy installation. With a coverage area of 115 m² and support for 200+ concurrent clients, it’s perfectly suited for small to medium-sized offices, classrooms, retail spaces, and residential applications. The device features UV-stabilized polycarbonate construction and operates reliably in temperatures from -30° to 40° C.
As part of the UniFi ecosystem, the U7 Lite offers the same comprehensive feature set as its higher-end counterparts, including wireless meshing, band steering, fast roaming (802.11k/v/r), and advanced guest management with customizable captive portal options. Managed through UniFi Network version 9.0.114 or later, it provides network administrators with enterprise-grade control over radio resources, client policies, and security settings. The U7 Lite represents an exceptional value proposition for organizations seeking to future-proof their wireless infrastructure with WiFi 7 technology while maintaining a conservative budget.
Overview
| Specification | Details |
|---|---|
| Dimensions | Ø171.5 x 33 mm (Ø6.8 x 1.3″) |
| WiFi Standard | WiFi 7 (802.11be) |
| Spatial Streams | 4 |
| Coverage Area | 115 m² (1,250 ft²) |
| Max. Client Count | 200+ |
| Uplink | 2.5 GbE |
| Mounting | Ceiling, Wall (Lite Mount Included) |
| Power Method | PoE |
Performance
| Specification | Details |
|---|---|
| MIMO (5 GHz) | 2×2 (DL/UL MU-MIMO) |
| MIMO (2.4 GHz) | 2×2 (DL/UL MU-MIMO) |
| Max. Data Rate (5 GHz) | 4.3 Gbps (BW240) |
| Max. Data Rate (2.4 GHz) | 688 Mbps (BW40) |
| Antenna Gain (5 GHz) | 5 dBi |
| Antenna Gain (2.4 GHz) | 4 dBi |
| Max. TX Power (5 GHz) | 24 dBm |
| Max. TX Power (2.4 GHz) | 23 dBm |
| Max. BSSIDs | 8 per Radio |
| Supported Data Rates | 802.11be (WiFi 7): 7.3 Mbps to 4.3 Gbps 802.11ax (WiFi 6): 7.3 Mbps to 2.4 Gbps 802.11ac (WiFi 5): 6.5 Mbps to 1.7 Gbps 802.11n: 6.5 Mbps to 300 Mbps |
Features
| Feature | Supported |
|---|---|
| Wireless Meshing | ✓ |
| Band Steering | ✓ |
| 802.11v BSS Transition Management | ✓ |
| 802.11r Fast Roaming | ✓ |
| 802.11k Radio Resource Management (RRM) | ✓ |
| Advanced Radio Management | ✓ |
| Passpoint (Hotspot 2.0) | ✓ |
| Captive Hotspot Portal | ✓ |
| Custom Branding Landing Page | ✓ |
| Voucher Authentication | ✓ |
| Payment-Based Authentication | ✓ |
| External Portal Server Support | ✓ |
| Password Authentication | ✓ |
| Guest Network Isolation | ✓ |
| Private Pre-Shared Key (PPSK) | ✓ |
| WiFi Speed Limiting | ✓ |
| Client Device Isolation | ✓ |
| WiFi Schedules | ✓ |
| RADIUS over TLS (RadSec) | ✓ |
| Dynamic RADIUS-assigned VLAN | ✓ |
Hardware
| Specification | Details |
|---|---|
| Max. Power Consumption | 13W |
| Supported Voltage Range | 42.5—57V DC |
| Networking Interface | (1) 2.5 GbE RJ45 Port |
| Weight | 313 g (11 oz) |
| Management | Ethernet |
| Enclosure Material | UV-stabilized polycarbonate |
| Mount Material | UV-stabilized polycarbonate, Galvanized steel (SGCC) |
| LEDs | System: White/Blue |
| NDAA Compliant | ✓ |
| Certifications | CE, FCC, IC, Anatel, SRRC |
| Operating Temperature | -30 to 40° C (-22 to 104° F) |
| Operating Humidity | 5 to 95% non-condensing |
Software
| Specification | Details |
|---|---|
| Application Requirements | UniFi Network Version 9.0.114 and later |
| Mobile App (iOS) | Version 10.20.2 and later |
| Mobile App (Android) | Version 10.21.7 and later |
